Stainless Steel Electromagnetic Flow Meter

Name: Stainless Steel Electromagnetic Flow Meter
Brand: ENVIRO EMPIRICAL (INDIA) PRIVATE LIMITED

Get a Price/Quote

MOQ : 1 Unit

Stainless Steel Electromagnetic Flow Meter Specification

Temperature Range
-20C to +60C

Frequency
50/60 Hz

Humidity %
5% ~ 95% RH

Capacity
Up to 30,000 m3/h

Current Range
4-20mA Output

Connectivity Type
4-20mA, RS485 (Modbus), Pulse Output

Sensor Type
Electromagnetic

Protection
IP65 / IP68

Application Media
Conductive Liquids

Resolution
0.001 m3/h

Pressure Range
Up to 4 MPa

Measurement Range
Based on selected diameter (customizable)

Equipment Type
Electromagnetic Flow Meter

Diameter
15mm to 600mm

Flow Rate
Real-time, totalized

Material
Stainless Steel

Power Supply
220V AC / 24V DC

Power Consumption
20W

Accuracy
0.5% of reading

Display Type
LCD Digital Display

Range
0.3 - 10 m/s

Enclosure Material
Powder Coated Aluminum

Output Signal
4-20mA, Pulse, RS485

Self-Diagnosis Function
Yes

Power Failure Data Storage
Yes

Weight
Varies by size (e.g. 25kg for DN100)

Ambient Temperature
-10C to 60C

Mounting Type
Flange or Wafer

Installation Position
Horizontal or Vertical

Display Units
Selectable (L/h, m3/h, etc.)

Electrode Material
SS316L, Hastelloy, Titanium, Tantalum, Platinum-Iridium

Empty Pipe Detection
Yes

Ingress Protection
Up to IP68 for sensor, IP65 for transmitter

Liner Material
PTFE, Rubber, or customized

Data Logging
Optional Data Logger available

Communication Protocols
Modbus, Hart (optional)

Stainless Steel Electromagnetic Flow Meter Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Stainless Steel Electromagnetic Flow Meter

Utilise this premier Stainless Steel Electromagnetic Flow Meter to optimise flow measurement for conductive liquids across diverse industry settings. With rare electrode material options such as SS316L, Hastelloy, Titanium, and even Platinum-Iridium, the device delivers inestimable value through customisation and prodigious performance. Benefit from selectable liners (PTFE/Rubber/custom), flange or wafer mounting, and superior protection up to IP68. Advanced features, including self-diagnosis, empty pipe detection, and data logging, make it ideal for modern, data-driven operations. Personalise output signals and display units for any application environment.

Exceptional Features and Versatile Applications

This flow meter's self-diagnosis, empty pipe detection, power failure data storage, and optional data logger equip operators with invaluable control and insight. Its robust, powder-coated aluminum enclosure and adaptable mounting suit challenging industrial sites such as water treatment, chemical processing, and food & beverage sectors. Personalise the system with various electrode and liner configurations for rare or demanding process conditions. Horizontal or vertical installation flexibility further enhances its real-world applicability.

Certifications, Supply Ability, and Export Markets

Each unit is rigorously certified for industry compliance, ensuring reliability and secure performance. With a prodigious supply capacity, we support bulk drop-off and timely delivery. Secure shipping methods safeguard the meter throughout its transit, guaranteeing product integrity. Our main export markets extend across Asia, the Middle East, Africa, and Europe, where clients trust our standard for inestimable quality and consistent delivery, backed by robust after-sales service and technical support.

FAQ's of Stainless Steel Electromagnetic Flow Meter:

Q: How does the Stainless Steel Electromagnetic Flow Meter ensure accurate readings?

A: The flow meter utilises advanced electromagnetic sensing and premier electrode materials, delivering up to 0.5% accuracy. Features like self-diagnosis and empty pipe detection further enhance measurement reliability and consistency.

Q: What options are available to personalise the meter for my application?

A: You can specify electrode materials (SS316L, Hastelloy, Titanium, Tantalum, Platinum-Iridium), liner types (PTFE, Rubber, customised), mounting style, output signals, and display units. This ensures a tailored solution for your process media and environmental conditions.

Q: Where is the Stainless Steel Electromagnetic Flow Meter typically installed?

A: It is ideal for installations in horizontal or vertical pipelines carrying conductive liquids. Common locations include water treatment facilities, chemical plants, and food processing environments.

Q: What is the process for secure shipping and delivery?

A: Each meter is carefully packaged using protective materials, tracked during transit, and delivered promptly to your site. Secure shipping minimises risk and ensures the product arrives in optimal condition.

Q: What are the main usage benefits of this flow meter?

A: Operators benefit from reliable, real-time flow monitoring, inestimable data storage during power failures, and compatibility with major communication protocols such as Modbus and HART for seamless system integration.
