Ultrasonic Clamp On Flow Meter

Name: Ultrasonic Clamp On Flow Meter
Brand: ENVIRO EMPIRICAL (INDIA) PRIVATE LIMITED
Price: 65000 INR
Availability: InStock

Price 65000 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Ultrasonic Clamp On Flow Meter Specification

Resolution
0.25 mm/s

Port Size
DN15 to DN600 compatible (pipe OD: 20mm~600mm)

Test Range
0.01 m/s~5 m/s

Power Supply
100-240V AC, 50/60Hz

Humidity
85% RH

Measuring Range
32 m/s

Gas Pressure
Atmospheric

Operating Voltage
9-28V DC (if required, external adapter optional)

Interface Type
RS232/RS485, Modbus RTU

Features
Non-invasive, Clamp-on, Portable, Data Logger, Easy Installation

Response Time
500 ms

Automation Grade
Automatic

Application
Liquid flow measurement in closed pipes

Temperature
-30C to +160C (sensor); -20C to +60C (main unit)

Frequency
1 MHz to 7 MHz (according to sensor and pipe size)

Accuracy
1.0% of reading

Mounting Type
Wall Mount/Handheld

Display Type
LCD, backlit

Equipment Type
Ultrasonic Clamp On Flow Meter

Usage
Industrial, Commercial, Water Supply, HVAC

Machine Weight
2.4 kg (main unit)

Control Mode
Keypad and Digital Display

Pipe Material Supported
Steel, Stainless Steel, Copper, PVC, Aluminum, Cast Iron, and others

Language Support
Multilingual display (English/Chinese)

Ingress Protection
Main Unit: IP65, Sensor: IP67

Data Storage
Up to 512 daily/monthly/hourly records

Enclosure Material
ABS Engineering Plastic (main unit)

Mediums Supported
Water, waste water, oil, chemicals, alcohol, etc.

Transducer Cable Length
Standard 5m (max up to 50m optional)

Ultrasonic Clamp On Flow Meter Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
10 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Ultrasonic Clamp On Flow Meter

Jump on the opportunity to experience a distinguished solution for liquid flow measurement with our Ultrasonic Clamp On Flow Meter. This virtuoso device supports pipe materials like steel, stainless steel, copper, PVC, aluminum, and more, while adeptly measuring a diverse array of mediums-water, oil, chemicals, and beyond. Its majestic features include a non-invasive, easy installation design, data logging for up to 512 records, and advanced ingress protection (IP65/IP67). With versatile connectivity and a backlit LCD display, this automatic industrial-class flow meter delivers exceptional value, performance, and reliability for every professional application-all backed by a robust promotion for exporters, manufacturers, and service providers across India.

Surface Application and Material Excellence

This Ultrasonic Clamp On Flow Meter stands out for its adaptability across multiple application surfaces, including steel, stainless steel, PVC, copper, and more. With robust ABS engineering plastic housing and sensor ingress protection up to IP67, it's ready for challenging environments. The meter's non-invasive design ensures accurate readings in closed pipes without process interruption. Notable features include a wide temperature tolerance, multilingual display, and the flexibility of wall mounting or handheld operation, making it a perfect fit for commercial and industrial domains.

Certifications, Market Presence, and Seamless Transactions

Our Ultrasonic Clamp On Flow Meter is delivered to clients with meticulous packaging to ensure safe transportation. Order processing is efficient, catering to India's largest industrial and commercial hubs with a strong domestic market presence. Payment terms are designed to suit various business needs, providing reliability and flexibility. Certifications meet the stringent quality benchmarks demanded in the automation and water supply industry, assuring customers of authenticity and dependable operation on every order placed.

FAQ's of Ultrasonic Clamp On Flow Meter:

Q: How is the Ultrasonic Clamp On Flow Meter installed and used?

A: The Ultrasonic Clamp On Flow Meter is designed for easy, non-invasive installation. Simply clamp the sensors onto the outside of the compatible pipe without cutting or modifying the pipeline. The device can then be operated via keypad and LCD display for immediate flow readings.

Q: What are the main benefits of using this flow meter over traditional meters?

A: Unlike traditional flow meters, this clamp-on device requires no process downtime or line intrusion, making it safer and more versatile. It offers quick installation, high accuracy (within 1.0% of reading), and data logging capabilities for up to 512 records, providing significant value and convenience.

Q: Where can the Ultrasonic Clamp On Flow Meter be applied?

A: This flow meter is ideal for industrial, commercial, water supply, and HVAC systems. It measures liquids such as water, wastewater, oil, chemicals, and alcohol in closed pipes made of steel, PVC, copper, and other materials, making it suitable for diverse environments.

Q: What is the data storage capacity and what kind of data can be recorded?

A: The meter can store up to 512 daily, monthly, or hourly flow records, allowing for detailed analysis and reporting of fluid movement over time directly through its data logging feature.

Q: How does the order process and delivery for this flow meter work?

A: Orders are processed promptly and the flow meter is delivered using secure packaging to ensure safety during transit. We support a variety of payment terms, making the transaction easy and flexible for businesses across India's principal industrial regions.
